0.6-6mm, model GLK4

  • Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material)
  • Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material)
  • Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material)
  • Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material)
  • Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material)
Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material) Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material) Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material) Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material) Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material)

Decoiler straightener feeder 3 in 1, model GLK4-H (0.6-6mm, for high tensile material)

  • Brand: GOODMAC
  • Model: GLK4-600H, GLK4-800H, GLK4-1000H, GLK4-1300H, GLK4-1600H
  • Applicable material: Steel, aluminum, brass, copper, etc
  • Coil car for coil: optional
  • Decoiler expanding type: hydraulic
  • Pressing arm for coil: standard
  • Decoiling input direction: from up to up
  • Feeding direction: from left to right, or from right to left
  • Uncoiler and feeder synchronizes : loop control by sensor
  • INQUIRY

This series machine contains decoiler, straightener, and NC servo roll feeder, so as 3 in 1 coil feed line.
It can decoil sheet metal strip coil, then straighten it, then feed it to press machine automatically, for automatic stamping & punching.
It has perfect straightening performance and precise feeding performance.
It can be customized according to your special application requirement.
Welcome to contact us for more details.


ModelGLK4-600HGLK4-800HGLK4-1000HGLK4-1300HGLK4-1600H
Coil strip width70-600mm70-800mm70-1000mm70-1300mm70-1600mm
Strip thickness0.6-6mm
Decoiler loading capacity5000KGS7000KGS10000KGS15000KGS
Coil inside diameterΦ508mm
Decoiler mandrel expandingby hydraulic cylinder
Coil outside diametermaximum Φ1400mm
Feeding length per strokemaximum 9999.99 mm
Feeding speed16-24 m/min
Feeding precision±0.15mm
Feeding line height1200±100mm
Straightener roller9 pieces (upper 5 / lower 4)
Feeding roller2 pieces
Back pressure rollerstandard
Electrical power380V, 3 phase, 50HZ
Pneumatic pressure5 kgf/cm2
Servo motor11KW11KW15KW15KW22KW
Decoiler motor2.2KW2.2KW3.7KW5.5KW7.5KW


Straightening capacity (when material yield strength is 600N/mm², tensile strength is 960N/mm².)
Modelthickness × width
0.51.21.62.02.32.52.83.24.04.55.06.0
GLK4-600H600568490376298219155127120
GLK4-800H800700645530400320235190150120
GLK4-1000H1000750670590470420300235157120
GLK4-1300H13001230110010501010590475435315240175120
GLK4-1600H160014001330100094590087055033027519098
